Overview:

The Unity RAW 1.7 is a full-color, ILDA-compatible, RGB diode-based laser projector. It is a cost-effective laser show system equipped with the capability to produce mesmerizing aerial beam effects and highly detailed laser graphics, logos, and text. Ideal for consumer and home applications.



Specifications:

Product Name: Unity RAW 1.7
Type Of Laser: Full-colour, Semiconductor diode laser system
Guaranteed Optical Output: >1,700mW
Suitable For: Small-sized venues and indoor events; laser shows and laser graphic displays
Control Signal: ILDA - We recommend Pangolin FB3QS and QuickShow
Scanning System: 25kpps @ 8°
Scan Angle: max. 50°
Safety: Fully complies with the latest EN 60825-1 and FDA regulations
Weight: 5.3kg
Package Includes: Laser projector, mains-power cable, 10M ILDA signal cable, E-STOP Remote with 10M XLR cable, set of 4 safety keys, 3-pin interlock bypass plug [for the US only], USB drive with a User Manual, QC certificate.
R | G | B [mW]: 350 | 500 | 1000
Beam Size [mm]: 5 x 3
Beam Divergence: <1.1mrad [Full Angle]
Modulation: Analog 50kHz
Power Requirements: 100-230V/50Hz
Consumption: Max. 100W
Operation Temperature: 10-40 °C
Ingress Rating: IP 20
System Features: All the adjustments such as power output of each colour, X & Y axes invert, X & Y size and position, etc. Scanning system protection, a daisy chain of emergency STOP signal for multiple system "one-hit" operation.
Laser Safety Features: Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety, Mechanical shutter, Adjustable aperture masking plate.
Notice: *Due to Advanced Optical Correction technology used in our laser systems, each laser colour's optical power output may slightly differ from the specification of the respective laser module(s) installed. This does not affect the total guaranteed power output.
Dimensions [mm]: Depth: 230
Width: 299
Height: 126
